石笼网
石笼网是金属线材编织的角形网(六角网)制成的网箱,使用的金属线径是根据六角形的大小而不同.如果是金属镀层的金属线六角形,则使用线径为2.0mm到4.0mm的金属线,如果是PVC包覆的金属线编织的六角网,则使用外径为3.0mm到4.5mm的PVC(金属)线.外框边缘的线则使用比六角网线粗一号的线。

石笼网箱为一次成型生产，除盖板外，边板，端板，及底板间不可分割。长度/宽度公差（±5%）高度公差（±10%），内部每隔1米采用隔板隔成独立的单元。加筋石笼网箱采用组装方式，盖板，边板，端板，底板单独生产组装成网箱，各部分用螺旋钢丝缠绕捆绑，网箱所有边丝均采用粗丝加强石笼网的强度。

石笼网

石笼网
网孔名义尺寸 (mm)	使用线径(金属线) (mm)	使用线径(PVC金属线)/ 内径/外径(mm)	捻纹数
60X80	φ2.0-2.8	φ2.0/3.0-2.5/3.5	3
80X100	φ2.0-3.2	φ2.0/3.0-2.8/3.8	3
80X120	φ2.0-3.2	φ2.0/3.0-2.8/3.8	3
100X120	φ2.0-3.4	φ2.0/3.0-2.8/3.8	3
100X150	φ2.0-3.4	φ2.0/3.0-2.8/3.8	3
120X150	φ2.0-4.0	φ2.0/3.0-3.0/4.0	3
